LM2596 DC-DC step up down boost buck voltage power converter module

Brand: Robo Inventors

36 review

MRP : ~~450.00~~

Price : 400.00 FREE Delivery ( Inclusive of all taxes )

You Save: 50

Sold By: Unicorpse

Module Properties: non-isolated step-up & down module (BOOST & Buck).
Input voltage: 3.2-32V. Output voltage: (1) continuously adjustable (1.2-35V).
Output Current: 1.5A (MAX). Input Current: 4A (MAX).
Output power: natural cooling 20W, plus heat sink 25W (MAX) real power.
Output power: natural cooling 20W, plus heat sink 25W (MAX) real power

10 Available

Add to Cart

Buy Now

SKU: TH2028Th401

Categories:Robotics, Sensor

Tags : LM2596 DC-DC step up down, boost buck voltage

Parameters - Module Properties: non-isolated step-up & down module (BOOST & Buck). Input voltage: 3.2-32V. Output voltage: (1) continuously adjustable (1.2-35V). Output Current: 1.5A (MAX). Input Current: 4A (MAX). Output power: natural cooling 20W, plus heat sink 25W (MAX) real power. Maximum output power = input voltage conversion efficiency * 4A *conversion efficiency. Operating temperature: Industrial grade (-40 C to + 85 C) (ambient temperature exceeds 40 degrees, lower power use, or to enhance heat dissipation). Full load temperature rise: 45 C. Operating frequency: 400khz. Load current: 5V turn 12V 15mA. Load regulation: ± 0.5%. Voltage regulation: ± 0.5%. Dynamic response speed: 5 0uS.
